eSSL EC-20M / EC-20K – Complete Elevator Access Control System
The eSSL EC‑20M / EC‑20K elevator access control solution delivers secure, floor‑wise access management for multi‑storey buildings. The EC‑20M main controller (20 floors / 20,000 cards / 100k events) can be expanded with EC‑20K extension boards – up to 60 floors total. Full TCP/IP networking, fire‑alarm input, Wiegand reader support and centralised management make it the ideal choice for hotels, residential towers, corporate offices and hospitals.
The eSSL EC‑20M / EC‑20K elevator access control system is a modern, IP‑based solution designed to manage who can access which floor in a building. The EC‑20M main controller supports up to 20 floors natively; when paired with up to two EC‑20K expansion boards, you can control up to 60 floors from a single controller. All floor access decisions are made in real time, logged, and can be managed centrally over TCP/IP.
🔑 Core Elevator Access Control Capabilities
✅ Flexible Floor Capacity
EC‑20M handles 20 floors natively. Add one or two EC‑20K boards to reach 40 or 60 floors – perfect for mid‑ to high‑rise buildings.
EC‑20M handles 20 floors natively. Add one or two EC‑20K boards to reach 40 or 60 floors – perfect for mid‑ to high‑rise buildings.
✅ 20,000 Cardholders / 100,000 Events
Manage access for thousands of residents, employees or guests while keeping a complete audit trail of every elevator transaction.
Manage access for thousands of residents, employees or guests while keeping a complete audit trail of every elevator transaction.
✅ TCP/IP Ethernet Networking
Connect controllers to your building LAN/WAN for real‑time monitoring, remote floor‑access configuration and instant event uploads.
Connect controllers to your building LAN/WAN for real‑time monitoring, remote floor‑access configuration and instant event uploads.
✅ Time‑Based & Group‑Wise Access
Define who can go to which floor and during which time slots (e.g. unrestricted during business hours, restricted after hours).
Define who can go to which floor and during which time slots (e.g. unrestricted during business hours, restricted after hours).
✅ Wiegand 26/34 Reader Input
Connect the EC‑20M to any RFID card reader, biometric fingerprint reader or face recognition terminal – you choose the credential.
Connect the EC‑20M to any RFID card reader, biometric fingerprint reader or face recognition terminal – you choose the credential.
✅ Fire Alarm Integration
A dedicated fire signal input overrides all floor restrictions during an emergency, freeing the elevators for safe evacuation.
A dedicated fire signal input overrides all floor restrictions during an emergency, freeing the elevators for safe evacuation.
✅ Power‑Off Data Retention
All card data and the 100,000‑event transaction log are stored in high‑speed non‑volatile memory – no data loss after a power cut.
All card data and the 100,000‑event transaction log are stored in high‑speed non‑volatile memory – no data loss after a power cut.
✅ Centralised Management Software
Works with eSSL access management software (all‑in‑one portal for access control, elevator control and time attendance).
Works with eSSL access management software (all‑in‑one portal for access control, elevator control and time attendance).
📊 Technical Specifications – EC‑20M (Main Elevator Access Controller)
| Floor Outputs (built‑in) | 20 floors |
|---|---|
| Card Capacity | 20,000 users |
| Event Buffer | 100,000 records (retained during power interruption) |
| Communication to PC | TCP/IP 10/100 adaptive, RS‑485 |
| Reader Input | 1 × Wiegand 26/34 (supporting RFID / biometric / keypad readers) |
| Fire Alarm Input | 1 line (emergency release of all floors) |
| Power Supply | 12 V DC (professional access power supply recommended) |
| EC‑20M PCB Size | 164 × 106 mm |
| Compatible Expansion Board | EC‑20K (adds 20 floor outputs) |
📡 EC‑20K Floor Expansion Board – Extend Your Elevator Access Control Coverage
| Function | Adds additional independent floor‑button relay outputs |
|---|---|
| Output Lines | 20 per board |
| Maximum Expansion per EC‑20M | 2 boards (total floors: 20 + 20 + 20 = 60) |
| Communication to EC‑20M | RS‑485 |
| EC‑20K PCB Size | 219 × 115 mm |
| Application | Tall multi‑storey buildings where more than 20 floors need individual access control |
🏢 Where to Deploy the eSSL Elevator Access Control System
🏨 Hotels & Resorts
Give guests access only to their assigned floor plus public areas (lobby, restaurant, spa). No need for physical keys – works with RFID cards or mobile credentials.
Give guests access only to their assigned floor plus public areas (lobby, restaurant, spa). No need for physical keys – works with RFID cards or mobile credentials.
🏢 Residential Towers & Condominiums
Residents reach their own floor, the parking level and common areas. Visitors are escorted or given temporary floor access.
Residents reach their own floor, the parking level and common areas. Visitors are escorted or given temporary floor access.
🏢 Corporate Offices & IT Parks
Restrict floors to specific departments (e.g. HR, finance, executive suites) while allowing staff access to the cafeteria and meeting rooms.
Restrict floors to specific departments (e.g. HR, finance, executive suites) while allowing staff access to the cafeteria and meeting rooms.
🏥 Hospitals & Medical Facilities
Secure access to ICUs, surgery wings and administrative floors. Public floors (reception, outpatient) remain open.
Secure access to ICUs, surgery wings and administrative floors. Public floors (reception, outpatient) remain open.
🌟 Why choose eSSL Pune as your elevator access control partner?
Genuine eSSL hardware
We supply factory‑fresh EC‑20M and EC‑20K boards with full manufacturer warranty and compliance.
We supply factory‑fresh EC‑20M and EC‑20K boards with full manufacturer warranty and compliance.
Expert installation & support
Our Pune‑based engineers handle everything – wiring, reader integration, software setup and staff training.
Our Pune‑based engineers handle everything – wiring, reader integration, software setup and staff training.
Integration with HRMS / payroll systems
Export elevator usage logs to Spine, GreytHR, HROne, Zoho CRM, Candle, Saral, Oracle and other business platforms.
Export elevator usage logs to Spine, GreytHR, HROne, Zoho CRM, Candle, Saral, Oracle and other business platforms.
Competitive pricing & extended warranty
Best‑in‑class rates for the full elevator access control package, plus optional AMC plans for worry‑free maintenance.
Best‑in‑class rates for the full elevator access control package, plus optional AMC plans for worry‑free maintenance.
❓ Frequently Asked Questions – Elevator Access Control
What is included in the eSSL EC‑20M / EC‑20K elevator access control system?
The system consists of the EC‑20M main controller (supports up to 20 floors, 20,000 cards, 100,000 events) and optional EC‑20K expansion boards (each adds 20 extra floor outputs, up to 2 boards per controller). It works with Wiegand 26/34 card or biometric readers and communicates via TCP/IP for real‑time central management.
How many floors can the EC‑20M + EC‑20K elevator access control system handle?
The EC‑20M main controller handles up to 20 floors natively. Each EC‑20K expansion board adds 20 more floor outputs. One EC‑20M supports up to two EC‑20K boards, giving a total of 60 floors. Taller buildings can integrate multiple EC‑20M controllers on the same network.
What authentication methods does the EC‑20M support?
The EC‑20M includes one Wiegand 26/34 input port, so you can connect virtually any card reader, biometric reader (fingerprint, face recognition) or keypad. This gives you complete flexibility to choose the right credential for your building.
Does the system store access records during a power cut?
Yes. The controller uses high‑speed non‑volatile memory that retains all card data and the 100,000‑event transaction log even when the power is interrupted. Once power is restored, normal operation resumes with no data loss.
Can the elevator access control be integrated with a fire alarm system?
Absolutely. The EC‑20M has a dedicated fire signal input. When the building fire alarm is triggered, the controller can be configured to override all floor access restrictions, freeing all elevators for emergency evacuation.
